CHILLER CIRCULATOR

ZLTZ High-efficiency heat exchange unit

Cooling capacity2.6kW~16kW
RefrigerantR134A/R404A/R507C /R448
Temp control accuracy±0.3℃
Cooling TypeAir-cooling & Water-cooling

Suitable for temperature control applications such as microchannelreactors, plate heat exchangers, cold plates, heat sink plates, andtubular reactors with small heat exchange areas, large refrigerationcapacities, and small temperature differences; The equipment canautomatically recycle the thermal conductive medium;

ZLTZ -10℃~25℃

MODEL		ZLTZ-3	ZLTZ-6	ZLTZ-10	ZLTZ-15W	ZLTZ-20W	ZLTZ-30W	ZLTZ-40W	ZLTZ-75W	ZLTZ-100W	ZLTZ-150W
MODEL		ZLTZ-3W	ZLTZ-6W	ZLTZ-10W	ZLTZ-15W	ZLTZ-20W	ZLTZ-30W	ZLTZ-40W	ZLTZ-75W	ZLTZ-100W	ZLTZ-150W
TEMP CONTROL		-10℃ ~25℃
Cooling capacity	at 0℃	8.1kW	16.25kW	28.5kW	40.2kW	44.6kW	70.6kW	89.2kW	166.5kW	215kW	314.9kW
Cooling capacity	at -10℃	5.48kW	11kW	19.35kW	26.6kW	29.8kW	48.2kW	59.6kW	118kW	147.7kW	226.6kW

ZLTZ -40℃~20℃

MODEL		ZLTZ4-3	ZLTZ4-6	ZLTZ4-10	ZLTZ4-15W	ZLTZ4-20W	ZLTZ4-30W	ZLTZ4-40W	ZLTZ4-75W	ZLTZ4-100W	ZLTZ4-150W
MODEL		ZLTZ4-3W	ZLTZ4-6W	ZLTZ4-10W	ZLTZ4-15W	ZLTZ4-20W	ZLTZ4-30W	ZLTZ4-40W	ZLTZ4-75W	ZLTZ4-100W	ZLTZ4-150W
TEMP CONTROL		-40℃ ~20℃
Cooling capacity	at -10℃	5.2kW	11.15kW	18.4kW	26.3kW	31.6kW	48.2kW	70.2kW	124.3kW	160.4kW	271.9kW
	at -20℃	3.47kW	7.41kW	12.3kW	18.35kW	21.4kW	31.4kW	46kW	100.1kW	134kW	207.8W
	at -30℃	2.24kW	4.81kW	7.92kW	11.8kW	12.67kW	19.16kW	28.2kW	68.3kW	90.4kW	142.3kW
	at -40℃	1.36kW	2.95kW	4.7kW	5.83kW	6.74kW	10.45kW	15.41kW	42.8kW	55.2kW	89.3kW

ZLTZ -80℃~-30℃

MODEL		ZLTZ8-3	ZLTZ8-6	ZLTZ8-10	ZLTZ8-15W	ZLTZ8-20W	ZLTZ8-30W	ZLTZ8-40W	ZLTZ8-75W	ZLTZ8-100W	ZLTZ8-150W
MODEL		ZLTZ8-3W	ZLTZ8-6W	ZLTZ8-10W	ZLTZ8-15W	ZLTZ8-20W	ZLTZ8-30W	ZLTZ8-40W	ZLTZ8-75W	ZLTZ8-100W	ZLTZ8-150W
TEMP CONTROL		-80℃~ -30℃
Cooling capacity	at -30℃
	at -40℃	6.9kW	14.8kW	24.4kw	36.7kW	42kW	73.2kW	110kW	187.5kW	257.5kW	365kW
	at -60℃	3.3kW	7.1kW	12kW	17.4kW	20kW	35kW	52.5kW	89.3kW	122.5kW	173.8kW
	at -75℃	1.65kW	3.55kW	6kW	8.7kW	10kW	17.5kW	26.2kW	44.7kW	61.3kW	87kW

Other configurations

Compressor	Inverter compressor
Throttling method	Electronic expansion valve
Operation panel	7-inch color touch screen/PLC controller
Communication	Modbus RTU protocol RS485 interface 、Ethernet TCP/IP protocol
Refrigerant	R134A
Interface size	G1/2	G1/2	G3/4
Water cooled at 20℃	1500L/H	3000L/H	4500L/H
	G1/2	G3/4	G3/4
Water-cooled condenser	The water-cooled equipment condenser uses plate heat exchangers and requires water supply from a chiller or a closed cooling tower
Air-cooled condenser	Microchannel Heat Exchanger	Microchannel Heat Exchanger	Microchannel Heat Exchanger
Power	380V 50HZ ,can choose three-phase 220V/460V
Pipe materials	Copper, SUS304
Shell material	Cold rolled sheet (standard color 7035)

Product Description

The ZLTZ temperature control unit is combined with a microchannelreactor to form a high heat release temperature control application.Under the same flow condition, the heat transfer efficiency of thetemperature control is more than 5 times that ofthe heat transfer oil.At the same time, the temperature difference between the inlet andoutlet is small, and the temperature field uniformity is high, which isparticularly suitable for applications with intense heat release reactions.

ZLTZ temperature control unit is used in combination with cold plateand heat sink plate for high heat absorption and high uniformitytemperature control.

The ZLTZ temperature control unit is combined with ESC chucks,vacuum chucks, etc. to achieve a temp control range of -65~200°CAt the same time, one ZLTZ temperature control unit with multipleESC chucks can control
