LTZ Inverter M Series

LTZ Inverter M Series

APPLICATIONS

Suitable for application to the target temperature control object already has a cold storage tank and a circulating pump, and the medium is transported into the LTZ M series refrigeration temperature control unit through the circulating pump to form a closed-loop refrigeration system.

Product Features

Mode LTZ-1 M LTZ-3M
LTZ-3WM
LTZ-6M
LTZ-6WM
LTZ-15M
LTZ-15WM
LTZ-25WM
Temp range 5 ℃~30℃  (Use glycol water below 10℃)
Temp control accuracy ±0.5℃
Temp feedback Pt100
Cooling capacity at 20℃ 3kW  10.5kW 21kW 52kW 87kW
Compressor Mitsubishi, Highly Inverter compressor
Throttling method Thermal Expansion Valve Electronic expansion valve
DI heat exchanger Plate Heat Exchanger
Input, Display 4.3-inch touch screen 7-inch color touch screen\PLC controller
Communication Modbus RTU protocol RS485 interface
Security
protection
Self-diagnosis function; refrigerator overload protection; high and low voltage protection, overload relay, thermal protection
device, exhaust and suction temperature protection, sensor fault protection and other safety protection functions
Refrigerant R407C
Interface size G1/2 G3/4 G3/4
Water-cooled at 20℃ 600L/H 1800L/H 3600L/H 9000L/H 15000L/H
G3/4 G1 DN32 PN10 DN40 PN10
Water-cooled condenser Water-cooling equipment adopts plate heat exchanger and requires closed cooling tower to supply water.
Air-cooled condenser Microchannel Heat Exchanger
Power supply 380V 50HZ can choose three-phase 220V 460V
Contact pipe material SUS304
Shell material Cold rolled sheet (REL7035)

APPLICATIONS

Semiconductor FAB process temperature control solution

Semiconductor packaging & testing process temperature control solution

The semiconductor packaging and testing process is a key link in the semiconductor production process, including wafer testing, chip packaging and post-packaging testing. This process not only requires a high degree of precision and reliability, but also requires strict control of temperature to ensure product quality and performance.

Microchannel | Tubular Reactor Temperature Control Solution

Aerospace materials | Test equipment temperature control solution

Temperature control solution for hydrogen energy industry

Temperature control solution for New material | Special gas production

New materials, as newly developed or developing structural materials with excellent performance and functional materials with special properties, have extremely high requirements for temperature control in their research and development and production processes. The production of special gases, such as oxygen, nitrogen, argon and other industrial gases, also requires precise temperature control to ensure product quality and production efficiency.

Temperature control solution for Distillation and concentration

The basic principle of distillation and concentration is to utilize the difference in volatility of the components in the mixture, vaporize the volatile components under heating conditions, and then collect them through condensation to achieve the purpose of separation and concentration. In this complex and delicate process, temperature control technology is not only the key to ensure smooth operation, but also an important factor affecting product quality and efficiency.

*
*
