SUNDIZ-45℃~250℃ thermal control unit includes cooling system, heating system, control system, circulation system, etc.
lowest
Highest
Temperature control accuracy
Medium & Material
Contact LNEYA sales engineer
for catalog or price.
| Model | SUNDIZ4-3 SUNDIZ4-3W |
SUNDIZ4-5 SUNDIZ4-5W |
SUNDIZ4-10 SUNDIZ4-10W |
SUNDIZ4-15W | SUNDIZ4-20W | SUNDIZ4-30W | |
| Temperature range | -45℃～250℃ | ||||||
| Heating power | 5.5kW | 7.5kW | 15kW | 25kW | 38kW | 60kW | |
| Cooling capacity kW | 250℃ | 5.5kW | 7.5kW | 15kW | 25 kW | 38kW | 60kW |
| 20℃ | 5.5kW | 7.5kW | 15 kW | 25kW | 38kW | 60kW | |
| -15℃ | 2.3kW | 3.6kW | 7.5 kW | 11kW | 15kW | 33kW | |
| -35℃ | 0.9kW | 1.5kW | 3.3 kW | 5kW | 6.5kW | 10kW | |
| Medium temp control accuracy | ±0.1℃ | ±0.1℃ | ±0.1℃ | ±0.1℃ | ±0.1℃ | ±0.1℃ | |
| Process temp control accuracy | ±0.3℃ | ±0.3℃ | ±0.3℃ | ±0.3℃ | ±0.3℃ | ±0.3℃ | |
| Pump flow rate pressure max | 50L/min | 50L/min | 100L/min | 150L/min | 250L/min | 400L/min | |
| 2bar | 2bar | 2bar | 2.5bar | 2.5bar | 2.5bar | ||
Variable frequency energy saving
The compressors, fans and pumps used in the SUNDIZ-45℃~250℃ chiller heater unit are all variable frequency, which can automatically control the output flow and pressure according to the actual cooling and heating needs, reduce power consumption, and save more than 20% energy compared to fixed frequency bandwidth.
Fully enclosed design
The SUNDIZ-45℃~250℃ thermal control unit adopts a fully enclosed pipeline design. The heat transfer medium is in a closed system. The heat transfer medium in the expansion container does not participate in the circulation. The expansion tank temperature is maintained at a room temperature of 60℃, which effectively reduces the risk of the heat transfer medium absorbing moisture and volatilizing during the operation of the chiller.
Industrial Manufacturing
In the process of anodizing and electroplating, the chiller heater combo is often used to control the temperature of the plating solution and the oxidation tank, thereby improving the treatment quality of the metal surface. In the casting process, it is used to control the temperature of the molten metal to prevent thermal stress from causing product defects. In chemical reactions, it is used to control the temperature of reactors and distillation equipment to improve the stability and yield of chemical reactions.
Medicine and Biotechnology
DNA synthesis, enzyme reactions, cell culture and other experiments require SUNDIZ-45℃~250℃ thermal control unit to help control the appropriate temperature range. In the pharmaceutical process, the temperature of the reactor, dryer and condensation system must be controlled by the chiller heater.
Cooling capacity 2.1kW~15kW
Heating power 3.5kW~15kW
Medium temp accuracy ±0.5℃
Material temp accuracy ±1℃
Cooling capacity 1.8kW~200kW
Heating power 3.5kW~200kW
Medium temp accuracy ±0.5℃
Material temp accuracy ±1℃
Cooling capacity 0.25kW~200kW
Heating power 2.5kW~200kW
Medium temp accuracy ±0.5℃
Material temp accuracy ±1℃
Cooling capacity 0.25kW~60kW
Heating power 2.5kW~60kW
Medium temp accuracy ±0.5℃
Material temp accuracy ±1℃
Cooling capacity 0.3kW~80kW
Heating power 3kW~80kW
Medium temp accuracy ±0.5℃
Material temp accuracy ±1℃
Cooling capacity 0.5kW~80kW
Heating power 5.5kW~80kW
Medium temp accuracy ±0.5℃
Material temp accuracy ±1℃
Cooling capacity 0.7kW~80kW
Heating power 5.5kW~80kW
Medium temp accuracy ±0.5℃
Material temp accuracy ±1℃
Cooling capacity 0.4kW~1.5kW
Heating power 2kW
Medium temp accuracy ±0.5℃
Material temp accuracy ±1℃
