boiler chiller systems

HRT -45℃～250℃

Supports an operating range of -45°C to 250°C, and a temperature control accuracy of up to ±0.5°C, meeting application requirements in the fields of medicine, chemical industry, new energy, semiconductors, aerospace, etc.

Send us about your inquiry

HRT series

-45°C

lowest

250°C

Highest

±0.5°C

Temperature control accuracy

Contact LNEYA sales engineer for catalog or price.

Cooling Capacity kW at	250℃	3.5kW	5.5kW	7.5kW	10kW	15kW
	100℃	3.5kW	5kW	7kW	10kW	15kW
	20℃	3.5kW	5kW	7kW	10kW	15kW
	0℃	3kW	5kW	7kW	10kW	15kW
	-15℃	1.5kW	2.8kW	4kW	5.5kW	10kW
	-35℃	0.45kW	0.9W	1.5kW	2kW	3.75kW
Criculation pump flow		Max35L/min	Max35L/min	Max50L/min	Max65L/min	Max110L/min
Pressure MAX		1.2BAR	1.2BAR	1.2BAR	1.5BAR	1.5BAR
Refrigerant		R-404A/R507C/R448A
Dimension cm		4570160	5570175	5570175	6585185	7085185
Weight		185kg	245kg	245kg	320kg	360kg
Power max AC 380V 50HZ		6.2kW	9kW	14kW	16kW	23kW

The key to ensuring high precision and high efficiency

LNEYA boiler chiller systems applications

LNEYA boiler chiller systemss can achieve stable, precise and efficient temperature control. The HRT series industrial chiller heater unit can continuously control the temperature between 250℃ and -45℃. Based on our ultra-high temperature cooling technology, direct compression cooling starting from 250 degrees Celsius is no problem.
The HRT series chiller heater has standard models of various sizes and performance configurations, which can be flexibly applied in various scenarios.

Send Inquiry Now

Other models for semiconductor industry

HR -25℃～200℃
boiler chiller systems

Cooling capacity 1.8kW~15kW
Heating power 3.5kW~15kW
Temp accuracy ±0.5℃

Learn more

HRT -40℃~250℃
heat recovery chiller

Cooling capacity 0.8kW~15kW
Heating power 3.5kW~15kW
Temp accuracy ±0.5℃

Learn more

The HRT industrial heater chiller has a self diagnostic function. If a fault occurs, the cause of the fault will be displayed at the top of the touch screen, making it convenient for you to troubleshoot in a timely manner.
HRT can control the temperature of the thermal medium within ± 0.5 ℃, but as an economical chiller heater, it does not support controlling the temperature of the reactants. If you need to control the temperature of the reactants, you can choose the SUNDI series.

Send Your Inquiry Now →

Global service

Served more than 30,000 customers.
Exported to more than 20 countries.

Certification patents

Has obtained CE certification, SGS certification, ISO certification.

After-sales service

Provide comprehensive technical training.
With 24/7 solutions.

Professional team

Founded in 2010, with 15 years of industry experience.
20% of employees are technicians.

Quality control

Visual inspection.
Performance test.
Electrical safety test.

Get in touch with our boiler chiller systems experts

Can’t find a suitable chiller? Or don’t know how to choose a chiller? Contact us now to get chiller details and prices

You need to keep the working environment of the chiller as ventilated and dry as possible. If the alarm function of the chiller prompts an abnormality, you need to stop working in time to solve it to avoid small problems causing big problems.

Yes, our recirculation chillers are exported to more than 20 countries, and we have agents in the United States, Canada, Australia, Russia, South Korea and other countries. You can contact the local agent or contact us directly to purchase equipment.

You need to provide the operating temperature range, cooling and heating power, flow requirements, temperature and humidity altitude of the use scenario, and tell us the control system, communication interface, etc. you need. Our technicians will guide you to provide all the required parameters.
